Contour Stainless Steel Toilet, Wall Supply

Find A Representative
Model 8955-W Series
Contains Recycled Material
CSA B125.1
ADA Compliant
Recyclable
ASME A112.19.3
Water Saving
WaterSense - Meets EPA Criteria certified by IAPMO R&T 1.28 gpf
Installation Instructions
3 available
Submittal
2 available
Ae 2141 W Fm Rang15g
Model 8955-W Series

Contour Stainless Steel Toilet, Wall Supply

The Contour Toilet with Wall Supply is configured for a concealed flush valve and includes a 1-1/2" NPTI flushing inlet connection at the rear of toilet housing. The concealed flush valve utilizes a commercial 1" (25 mm) water supply line. Wall waste toilets (8955-W-1 and 8955-W-2) shall be mounted on the wall with a wall waste rough-in 5-1/2" (140 mm) above finished floor. The floor waste toilet (8955-W-3) shall be mounted to finished wall with a floor waste 4-1/4" (108 mm) from finished wall.

  • Commercial SIPHON JET ToiletRequiring commercial water supply line to operate. Water flow pressure 35 psi (2.41 bars); Water supply line 1"(25 mm).
  • WALL SUPPLY (Concealed, In-Wall) Flush Valve ConfigurationCompatible flush valve (sold separately) releases 1.6 gallons (6 liters) per flush.
  • 16-Gauge STAINLESS STEEL CONSTRUCTIONSatin Finish is standard; Also available in Mira (high polish) Finish
  • Mounting/Wall Waste Configurations:
    • (-1) Off-Floor, Wall Waste
    • (-2) On-Floor, Wall Waste
    • (-3) On-Floor, Floor Waste
  • ELONGATED TOILET BOWLPunched for elongated toilet seat (not included) with 5-1/2" (140 mm) mounting centers.
  • ADA compliant toilets are available
  • ANSI A112.19.2 compliant

Downloads

Resource Type
Title
Description
File Size
Action
PDF icon
Installation Instructions
PDF icon
Installing 8955-W-1 Toilet (pdf)
Wall Supply, Off-Floor (also includes ADA install)190 KB
PDF icon
Submittals
PDF icon
Tech Sheet 8955-W (Wall Supply) Toilet (pdf)
Wall Supply Contour Toilet 8955-W-1 (Off-Floor); 8955-W-2 (On-Floor, Wall Waste); 8955-W-3 (On-Floor, Floor Waste)386 KB
RFA icon
Drawings
RFA icon
8955-W-2 Toilet (rfa)
Wall Supply Floor Mounted Contour Toilet with Wall Waste240 KB
RFA icon
Drawings
RFA icon
8955-W-2 Toilet (dwg/zip)
Wall Supply Floor Mounted Contour Toilet with Wall Waste118 KB
PDF icon
Installation Instructions
PDF icon
Installing 8955-W-2 Toilet (pdf)
Wall Supply, On-Floor, Wall Waste (also includes ADA Toilet)220 KB
PDF icon
Installation Instructions
PDF icon
Installing 8955-W-3 Toilet (pdf)
Wall Supply, On-Floor, Floor Waste (also includes ADA Toilet)191 KB
PDF icon
Technical Data Sheets
PDF icon
Cleaning Guidelines (pdf)
Cleaning guidelines for Neo-Metro products252 KB
PDF icon
Submittals
PDF icon
Spec Sheet SQ-0-2358Y WC Support (pdf)
Fixture Support Detail for Siphon Jet Water Closet for Acorn Engineering Model 2141-FM, Neo-Metro Model 8955142 KB

Specifications

AccessibilityADA Compliant
MaterialStainless Steel
Additional Accessibility NotesMust be specified: 8955-ADA-W-2, 8955-ADA-W-3 to be ADA compliant
Steel FinishSatin Finish Stainless Steel [STANDARD - plain model number], Enviro-Glaze® Powder Coating, -HP | Mira High Polish Stainless Steel
FlushingClassified as High Efficiency Toilet/Urinal, Wall Supply, Commercial 1" Supply @ 35 psi Required
Waste LocationWall Waste, 4.25" Floor Toilet Rough-In
Toilet Bowl ShapeElongated
Environmental/HealthWater Saving
CertificationsASME A112.19.3, WaterSense - Meets EPA Criteria certified by IAPMO R&T 1.28 gpf, CSA B125.1
Options2954-720-000 | In-Wall Toilet Carrier
MountWall Mounted, Floor Mounted

Options

Miscellaneous

Model
Description
Downloads
Option: Toilet Flush Valve
FV Toilet Series
Option: Toilet Flush Valve

Colors

Steel Finish

  • Satin Finish Stainless Steel [STANDARD - plain model number]

    Satin Finish Stainless Steel [STANDARD - plain model number]

  • Enviro-Glaze® Powder Coating

    Enviro-Glaze® Powder Coating

  • Mira High Polish Stainless Steel

    HP | Mira High Polish Stainless Steel

Models

Typical models are shown below

OFF-FLOOR, WALL SUPPLY MODELS

Wall Supply, Off-Floor, Wall Waste

8955-W-1

Off-Floor, Wall Waste

Toilet may also be used for ADA applications

[ install guide ]

ON-FLOOR, WALL SUPPLY MODELS

On-Floor, Wall Waste, Wall Supply

8955-W-2

On-Floor, Wall Waste

8955-ADA-W-2

ADA Compliant, Toilet is 3" taller)

[ install guide ]

On-Floor, Floor Waste, Wall Supply

8955-W-3

On-Floor, Floor Waste

8955-ADA-W-3

ADA Compliant, Toilet is 3" taller)

[ install guide ]
